What is TurtleBot?

TurtleBot is a low-cost, personal robot kit with open-source software. TurtleBot was created at Willow Garage by Melonee Wise and Tully Foote in November 2010. With TurtleBot, you’ll be able to build a robot that can drive around your house, see in 3D, and have enough horsepower to create exciting applications.

The TurtleBot kit consists of a mobile base, 2D/3D distance sensor, laptop computer or SBC(Single Board Computer), and the TurtleBot mounting hardware kit. In addition to the TurtleBot kit, users can download the TurtleBot SDK from the ROS wiki. TurtleBot is designed to be easy to buy, build, and assemble, using off the shelf consumer products and parts that easily can be created from standard materials. As an entry level mobile robotics platform, TurtleBot has many of the same capabilities of the company’s larger robotics platforms, like PR2.

For more information

For more information, we recommend an interview with TurtleBot creators, Tully Foote and Melonee Wise.

TurtleBot Inventors Tell Us Everything About the Robot (IEEE Spectrum, By Evan Ackerman, 26 Mar 2013)

Core Technology

The TurtleBot’s core technology is SLAM and Navigation, making it suitable for home service robots. The TurtleBot can run SLAM(simultaneous localization and mapping) algorithms to build a map and can drive around your room. Also, it can be controlled remotely from a laptop, joypad or Android-based smart phone. The TurtleBot can also follow a person’s legs as they walk in a room. Also included are the ROS arm navigation capabilities, an arm attachment that has been developed for manipulating objects.

History

TurtleBot1

TurtleBot1 consists of an iRobot Create base, a 3,000mAh battery pack, a TurtleBot power board with gyro, a Kinect sensor, an Asus 1215N laptop with a dual core processor, and a hardware mounting kit attaching everything together and adding future sensors. The first TurtleBot was created at Willow Garage by Melonee Wise and Tully Foote in November 2010.

TurtleBot2

TurtleBot2 consists of an Yujin Kobuki base, a 2,200mAh battery pack, a Kinect sensor, an Asus 1215N laptop with a dual core processor, fast charger, charging dock, and a hardware mounting kit attaching everything together and adding future sensors. Turtlebot2 was released on Oct 2012.

TurtleBot 2.0 Now Available for Preorder from Clearpath Robotics (IEEE Spectrum, By Evan Ackerman, 22 Oct 2012 )

TurtleBot3

TurtleBot3 is made up of modular plates that users can customize the shape. Available in three types: small size Burger and medium size Waffle, Waffle Pi. TurtleBot3 consists of a base, two Dynamixel motors, a 1,800mAh battery pack, a 360 degree LIDAR, a camera(+ RealSense camera for Waffle kit, + Raspberry Pi Camera for Waffle Pi kit), an SBC(single board computer: Raspberry PI 3 and Intel Joule 570x) and a hardware mounting kit attaching everything together and adding future sensors. Turtlebot3 was released on May 2017.

Robotis and OSRF Announce TurtleBot 3 Smaller, Cheaper, and Modular (IEEE Spectrum, By Evan Ackerman, 12 Oct 2016)

TurtleBot From Wikipedia

https://en.wikipedia.org/wiki/Turtlebot

Open Source

Software

The software is provided in full open-source. The main license is Apache License 2.0 .

TurtleBot3 Software

OpenCR Firmware

Hardware

The components of TurtleBot3 as a default are the following: the Chassis, the Motors, the Wheels, the OpenCR board, the Computer, the Sensor, the Battery. The chassis are the Waffle plates, the Board support, the Ball caster, etc. The big feature of the chassis is in the Waffle plate, which is the biggest in all TurtleBot3 parts, but is smaller than the hand. This plate will be provided as an injection molded, and it achieves the low cost, but the CAD data for 3D printing is also available. The TurtleBot3 Burger is a Two-wheeled differential drive type platform, but is able to be structurally and mechanically customized in many ways: the Cars, the Bikes, the Trailers and so on.

The CAD data is released to the Onshape, which is a full-cloud 3D CAD editor. Get access through a web browser by using the computer or even by the portable devices. Here allows the works of drawing, assemblying with the co-workers.

TurtleBot3 Hardware

TurtleBot3 Frineds Hardware

OpenManiapulator Hardware

OpenCR Hardware

Everything about the board; Schematics, PCB Gerber and BOM for the TurtleBot3 are free to distribute under open-source licenses for users and the ROS community.


Open Source License

Software License

Main software is released under the Apache License 2.0. However, some of the sources are under the licenses 3-Clause BSD License and GPLv3.

Hardware License

TurtleBot3 is an open source hardware project as described by the Open Source Hardware Statement of Principles and Definition v1.0.

Documents License

Documents are released under the CC BY 4.0.
